| Model: BR-3-T | 35112/24 | 50112/24 | 70124 | 70112 | 10212/24 | 15224/48 | 20248 | 20224 | 30224/48 | 40248/96 | |
| Pouvwa rated | 350W | 500W | 70W | 700W | 1000W | 1500W | 2000W | 2000W | 3000W | 4000W | |
| Pik pouvwa (20ms) | 1050W | 1500W | 2100W | 2100W | 3000W | 4500W | 6000W | 6000W | 9000W | 12000W | |
| Komanse mote | 0.3HP | 0.5HP | 0.5HP | 0.5HP | 1HP | 1.5HP | 2HP | 2HP | 3HP | 3HP | |
| batri voltaj | 12/24VDC | 24VDC | 12VDC | 12/24VDC | 24 / 48VDC | 48VDC | 24VDC | 24 / 48VDC | 48 / 96VDC | ||
| Anndan kontwole sole (Si ou vle) | 10A-30A (PWM) | 10A-60A (PWM oswa MPPT) | |||||||||
| Gwose (L * W * Hmm) | 335*210*122 | 410*143*210 | 400*180*320 | 420*208*348 | 460*245*445 | ||||||
| Pake Size (L * W * HMM) | 385*270*185 | 460*200*270 | 460*240*380 | 490*300*400 | 535*310*505 | ||||||
| N.W.(kg) | 6.5 | 8 | 10 | 11 | 13 | 18 | 21 | 23 | 29 | 46 | |
| G.W.(kg) | 7.5 | 9 | 11 | 12 | 14 | 19 | 22 | 24 | 30 | 48 | |
| Metod enstalasyon | Desktop | Tower | |||||||||
| Model: BR-3-T | 50248/96 | 60248/96 | 70296/192 | 10396/192 | 12396/192 | 153192/240 | 203192/240 | 253240 | 303240 | 403384 | |
| Pouvwa rated | 5000W | 6000W | 7000W | 10KW | 12KW | 15KW | 20KW | 25KW | 30KW | 40KW | |
| Pik pouvwa (20ms) | 15KW | 18KW | 21KW | 30KW | 36KW | 45KW | 60KW | 75KW | 90KW | 120KW | |
| Komanse mote | 4HP | 4HP | 5HP | 7HP | 7HP | 10HP | 10HP | 15HP | 15HP | 20HP | |
| batri voltaj | 48 / 96VDC | 96/192VDC | 192 / 240VDC | 240VDC | 240VDC | 384VDC | |||||
| Anndan kontwole sole (Si ou vle) | 10A-60A (PWM oswa MPPT) | 50A / 100A (PWM) | 50A / 100A / 150A / 200A (PWM) | ||||||||
| Gwose (L * W * Hmm) | 460*245*445 | 485*300*646 | 600*300*800 | 720*435*1120 | |||||||
| Pake Size (L * W * HMM) | 460*245*445 | 485*300*646 | 600*300*800 | 720*435*1120 | |||||||
| N.W.(kg) | 52 | 53 | 62 | 66 | 102 | 108 | 113 | 119 | 135 | 160 | |
| G.W.(kg) | 58 | 59 | 72 | 76 | 115 | 121 | 130 | 136 | 150 | 180 | |
| Metod enstalasyon | Tower | ||||||||||
| Opinyon | DC Antre Voltaj Range | 10.5-15VDC (sel voltaj batri) | |||||||||
| AC Opinyon voltaj Range | 73VAC-138VAC / 145VAC-275VAC (350W-7000W); 98VAC-250VAC (8KW-40KW) | ||||||||||
| AC Antre frekans Range | 45HZ-65Hz | ||||||||||
| Max AC chaje kouran | 15A MAX (Depann sou model la) | ||||||||||
| AC Chaje Voltaj | Plon batri: Chaje voltaj: 14V; Voltaj Flote: 13.8V (voltaj batri sel) | ||||||||||
| AC Chaje Metod | Twa-etap (konstan aktyel, voltaj konstan, flotan chaj) | ||||||||||
| Pwodiksyon | Efikasite (Mode batri) | ≥85% | |||||||||
| Pwodiksyon Voltaj (Mode batri) | 110VAC±2% / 220VAC±2% | ||||||||||
| Pwodiksyon frekans (Mode batri) | 50 / 60Hz±1% | ||||||||||
| Pwodiksyon Vag (mod batri) | Pi sinis vag | ||||||||||
| Efikasite (AC Mode) | >99% | ||||||||||
| Pwodiksyon Voltaj (AC mod) | 110VAC±2% / 220VAC±2% | ||||||||||
| Pwodiksyon frekans (AC Mode) | Swiv otomatikman | ||||||||||
| Pwodiksyon Waveform deformasyon (Mode batri) | ≤3 (chaj Lineye) | ||||||||||
| Pa gen chaj pet (Mode batri) | ≤2.5 rated pouvwa (Model anba a 7KW); ≤1 rated pouvwa (model pi wo a 7KW) | ||||||||||
| Pa gen chaj pet (AC Mode) | ≤2 rated pouvwa (chaje pa travay nan mod AC) | ||||||||||
| Pa gen chaj pet (ekonomize eneji mod) | ≤10W | ||||||||||
| Batri Kalite (Si ou vle) | Customize batri | Chaje ak paramet egzeyat nan diferan kalite pil ka Customized dapre kondisyon itilizate | |||||||||
| Pwoteksyon | Alarm pou batri savolte | 11V (voltaj batri sel) | |||||||||
| Batri pwoteksyon undervoltage | 10.5V (Voltaj batri sel) | ||||||||||
| Batri overvoltage alarm | 15V (voltaj batri sel) | ||||||||||
| Batri overvoltage pwoteksyon | 17V (voltaj batri sel) | ||||||||||
| Batri overvoltage gerizon voltaj | 14.5V (Voltaj batri sel) | ||||||||||
| Depase pwoteksyon pouvwa | Otomatik pwoteksyon (mod batri), kraze sikwi oswa asirans (AC mod) | ||||||||||
| Envese pwodiksyon kout pwoteksyon kout | Otomatik pwoteksyon (mod batri), kraze sikwi oswa asirans (AC mod) | ||||||||||
| Pwoteksyon tanperati | >90 ° C (Shutdown pwodiksyon) | ||||||||||
| Alarme | Yon | Nomal kondisyon ki ap travay, buzzer pa gen okenn son alarm | |||||||||
| B | Buzzer son 4 fwa pou chak dezyem le echek batri, voltaj anomali, overload pwoteksyon | ||||||||||
| C | Le se machin nan vire sou pou tan an dife, buzzer a pral rapid 5 le machin nan se nomal | ||||||||||
| Anndan kontwole sole (Si ou vle) | Chaje Mode | MPPT oswa PWM | |||||||||
| Kouran chaje | 12V / 24V / 48V Sistem; 10A, 20A, 30A, 40A, 50A, 60A; 96V / 192V / 240V / 384V Sistem; 50A, 100A, 150A, 200A | ||||||||||
| PV Antrepriz Voltaj Range | 12V Sistem: 15V-44V;24V Sistem: 30V-44V;48V Sistem: 60V-88V; 96V Sistem: 120V-176V; 192V Sistem: 240V-352V;240V Sistem: 300V-440V;384V Sistem: 480V-704V; | ||||||||||
| Max PV Antre voltaj * (nan 25 ° C) | 12V / 24V Sistem: 50V;48V Sistem: 100V;96V Sistem: 200V; 192V Sistem: 400V;240V Sistem: 500V;384V Sistem: 750V | ||||||||||
| PV Etalaj Maksimom pouvwa | 12V Sistem; 140W / 280W / 420W / 560W / 700W / 840W;24V Sistem: 280W / 560W / 840W / 1120W / 1400W / 1680W; 48V Sistem: 560W /1120W/1680W/2240W/2800W/3360W;96V Sistem:5.6KW/11.2KW/8.4KW*2/11.2KW*2 Sistem 192V:11.2KW/22.4KW/16.8KW*2/22.4KW*2;240V Sistem:14KW/28KW/21KW*2/28KW*2 Sistem 384V: 22.4KW / 44.8KW / 33.6KW * 2 / 44.8KW * 2 | ||||||||||
| Pet rete | ≤3W | ||||||||||
| Maksimom efikasite konvesyon | >95% | ||||||||||
| Mod travay | Batri Premye / AC Premye / Ekonomize eneji Mod | ||||||||||
| Transfe Tan | ≤4ms | ||||||||||
| Ekspozisyon | LCD | ||||||||||
| Metod temik | Refwadisman fanatik nan kontwol entelijan | ||||||||||
| Kominikasyon | RS232 (Si ou vle) | ||||||||||
| Anviwonman | Tanperati opere | 10 ° C-40 ° C | |||||||||
| Tanperati depo | 15 ° C-60 ° C | ||||||||||
| Bri | ≤5dB | ||||||||||
| Elevasyon | 2000m (Plis pase efase) | ||||||||||
| Imidite | 0%-95 (Pa gen kondansasyon) | ||||||||||
 NO1 |  NO2 |
 NO3 |  NO4 |
1) MOQ: 1 mete
2) Pri sistem total: yo dwe bay pa imel le yo resevwa espesifikasyon spesifikasyon kliyan an. Nou aksepte OEM.
3) Sijere achte tout sistem nan faktori nou an, panel sole gen 10 ane garanti, lot pati tout gen 2 ane garanti;
4) Pandan garanti a, pral bato pati yo gratis pou sevis, nou pwomet bon jan kalite nou an.
5) Pri Tem: EXW faktori
6) Tem Peman: 30 pa TT, balans.70 Kont kopi Bill oswa L / C nan je.
7) Akouchman: Machandiz yo ka pare pou chajman nan 7-15 jou ki ap travay sou resevwa peman.
8) Parantez kalite Roof, bezwen konfime materyel twa ou.
Objektif nou: Sipote chak kliyan ak bon jan kalite pwodwi ak sevis atantif, fe rev yo vini vre, Ansanm nou iminye mond lan.
Kesyon yo poze souvan
K1: Eske mwen ka gen yon lod echantiyon pou pwodwi sole?
A: Wi, akeyi lod echantiyon yo teste epi tcheke bon jan kalite. Echantiyon melanje yo akseptab.
K2: Ki sa ki sou tan an plon?
A: Egzanp bezwen jou 3-5, pwodiksyon mas bezwen 1-2 semen pou kantite lod plis pase yon sel veso
K3: Eske ou se yon faktori oswa yon konpayi komes?
A: Nou se faktori a ak kapasite pwodiksyon segonde ak seri pwodwi nan pwodwi sole nan Lachin.
K4: Ki jan yo chwazi sistem voltaj 12V / 24V?
A: Nou te kapab konsepsyon sistem nan pou ou. Anjeneral 12V sistem pou 15W-40W dirije lanp, 24V sistem pou 50-150W ki ap dirije lanp.
K5: Ki jan ou bato machandiz yo ak konbyen tan li pran yo rive?
A: Egzanp anbake pa DHL, UPS, FedEx, TNT elatriye Li anjeneral pran jou 3-5 rive. Airline ak anbake lanme tou si ou vle.
K6: Ki sa ki regleman garanti ou a?
A: Nou ofri 3 a 5 ane garanti pou sistem lan tout antye ak ranplase ak nouvo yo pou gratis nan ka ta gen bon jan kalite pwoblem.
